Tangling code from Hugo content with Raku

I could just use Org mode, but noo that's too easy

post raku-lang hugo literate-programming
You know what else I can tangle? Yarn!

2020-09-03

@codesections@fosstodon.org found a typo! I forgot to show the target file name once command line arguments are in place. It should go raku tangle-fragments.raku index.md.

Let’s say I have a file. The one you’re reading, perhaps. Well, its original Markdown content.

It has a shortcode in it.

Code sample
    {{< code file="hello.py" >}}
print("Hello")
{{< /code >}}

I based {{< code >}} here on a shortcode from the Hugo docs. It presents highlighted code with additional context.

Code sample
hello.py
     print("Hello")

Really handy when you’re writing about code. Thing is, now I have two copies. There’s one here in the shortcode, and another in a hello.py file that I’m writing about. I’d prefer there was only a single copy. That way they don’t get out of sync.

I could use Hugo’s readFile function in a new shortcode, including the contents of hello.py in this Markdown file. Something like this:

Code sample
    {{< include file="hello.py" >}}

Note

Actual shortcode logic left as an exercise for the reader.

But that still breaks up the writing flow a little bit. I’m writing the code over here, and writing about it over there. It’s a tiny complaint, but working with Org mode has spoiled me. I get to write the code in the same document that I’m writing about it in. Everything stays in sync, more or less.

What I want is to write about hello.py here, and with a command have hello.py appear on my filesystem, containing the Python code I’ve been describing.

And I want to do it without disturbing Hugo. Let it turn Markdown into HTML.

Tangling

This process is called “tangling,” and it’s popular in the admittedly small world of Literate Programming. The code is interleaved throughout some kind of document. A tool like noweb or Babel parses the document to create code files. Could be any kind of file, really. The process can get fancy.

But the start is not fancy: given a text file containing a {{< code file="(something)" >}}, write the contents of that shortcode to the named file.

Code sample
    sub MAIN() {
  my $filename = "index.md";
  my $opener = '{{< ';
  my $closer = ' >}}';
  my regex shortcode {
    $opener
      code \s
      'file="' $<filename> = .+? '"'  # Remember the filename
      .*?
    $closer
    \n                # Ignore leading newline
    $<content> = .+?  # Remember everything else in the block
    \n                # Ignore leading newline
    $opener '/code' $closer
  }

  my $markdown = slurp $filename;

  if $markdown.match(/ <shortcode> /) {
    my $tangle-file = $/<shortcode><filename>;
    my $tangle-content = $/<shortcode><content>;
    spurt $tangle-file, $tangle-content;
    say "Tangled to $tangle-file";
  }
}

I love Raku’s approach to regular expressions. For starters, the syntax looks a bit more like describing a grammar. I can break the funny regex characters up with spaces, and clarify them with comments. In fact, I could someday build this up to a real grammar.

Secondly, it addresses the fact that most text we look at these days contains multiple lines. I didn’t have to worry about any special multiline flags to get this working.

Finally, getting at the named captures was — I wouldn’t say “obvious,” but at least “coherent.” I can treat the match variable $/ as a nested Hash. The important bits look something like this::

Code sample
    shortcode =>
  filename => ｢hello.py｣
  content => ｢print("Hello")｣

I can grab the named capture filename of my matched shortcode regex with $/<shortcode><filename> — or ~$<shortcode><filename>, depending on your preferred syntax.

This is all possible in languages like Perl with assorted flags, but I haven’t seen parsing treated so well by default since maybe REBOL.

Anyways, let’s run this thing.

Code sample
    $ raku tangle.raku
Tangled to hello.py
$ bat hello.py
───────┬──────────────────────────────────────────────────────────────────────
       │ File: hello.py
───────┼──────────────────────────────────────────────────────────────────────
   1   │ print("Hello")
───────┴──────────────────────────────────────────────────────────────────────

Sweet.

Except — this Markdown file I’m writing. It has two file code blocks now. I want to tangle both of them.

Multiple output files

This requires a couple changes, since I’m writing code about Hugo shortcodes in a Hugo post.

To show shortcode directives without Hugo evaluating them, they need to look like shortcode comments. Their contents will get passed straight through as part of your post. To show {{< shortcode >}} in a post, your Hugo content needs {{</* shortcode */>}}.

So that’s lovely and all, but can be a headache of its own for this specific situation of extracting code from a blog post.

I need to remember this commented shortcode syntax.

Code sample
define-commented-shortcodes
     my $commented-opener = '{{' ~ '</* ';
 my $commented-closer = ' */>' ~ '}}';

Note

Goodness, that looks silly. Well, I’m writing this blog post as a test case for the code. I couldn’t figure out how to cleanly present the commented shortcode delimiters without Hugo and my code getting into a fierce argument.

If I wasn’t writing the code in this post, I could use something simpler, like this:

Code sample
    my $commented-opener = '{{​</* ';
my $commented-closer = ' */>}}';

But that’s not the path I chose. It’s not easy to write programs that write themselves. Sometimes you must help them along.

That way I can replace those commented shortcode delimiters with their normal counterparts when I tangle later.

Code sample
define-commented-shortcodes
    my $tangle-content = $block<shortcode><content>
  .subst(:global, / $commented-opener /, $opener)
  .subst(:global, / $commented-closer /, $closer);

Now that I have that particular detail out of the way, tangle every block? Sure! Make a regular expression match :global and it returns a list containing every match.

Code sample
tangle-every-block
    my $markdown  = slurp $filename;
my @fragments = $markdown.match(/<shortcode>/, :global);

for @fragments -> $block {
  my $tangle-file = $block<shortcode><filename>;
  «replace-commented-shortcodes»
  spurt $tangle-file, $tangle-content;
  say "Tangled to $tangle-file";
}

I think that about covers it. The shortcode recognition logic can stay the same.

Code sample
tangle-multi.raku
    sub MAIN() {
  my $filename = "index.md";
  my $opener = '{{< ';
  my $closer = ' >}}';

  my regex shortcode {
    $opener
      code \h
      'file="' $<filename> = .+? '"'  # Remember the filename
      .*?
    $closer
    \n                # Ignore leading newline
    $<content> = .+?  # Remember everything else in the block
    \n                # Ignore trailing newline
    $opener '/code' $closer
  }

  «define-commented-shortcodes»

  «tangle-every-block»
}

And it works!

Code sample
    $ raku tangle-multi.raku
Tangled to hello.py
Tangled to tangle.raku
$ bat tangle.raku
───────┬──────────────────────────────────────────────────────────────────────
       │ File: tangle.raku
───────┼──────────────────────────────────────────────────────────────────────
   1   │ sub MAIN() {
   2   │   my $filename = "index.md";
   3   │   my $opener = '{{< ';
   4   │   my $closer = ' >}}';
   5   │   my regex shortcode {
   6   │     $opener
   7   │       code \s
   8   │       'file="' $<filename> = .+? '"'  # Remember the filename
   9   │       .*?
  10   │     $closer
  11   │     \n                # Ignore leading newline
  12   │     $<content> = .+?  # Remember everything else in the block
  13   │     \n                # Ignore leading newline
  14   │     $opener '/code' $closer
  15   │   }
  16   │
  17   │   my $markdown = slurp $filename;
  18   │
  19   │   if $markdown.match(/ <shortcode> /) {
  20   │     my $tangle-file = $/<shortcode><filename>;
  21   │     my $tangle-content = $/<shortcode><content>;
  22   │     spurt $tangle-file, $tangle-content;
  23   │     say "Tangled to $tangle-file";
  24   │   }
  25   │ }
  ───────┴──────────────────────────────────────────────────────────────────────

Unfortunately, I’m not quite done yet.

Multiple fragments

I’m not done yet because I don’t like to describe my code a full file at a time. I’d rather talk about this bit here, explain that bit over there, then mash it all up in the end.

Consistency counts, so I need to pick a syntax. Well — you’ve been reading along. You can see that I already made my choice. I got used to <<fragment-name>> in Babel, where the attribute is called name. Might as well keep doing that over here. Oh but hang on. I want it to stand out a bit. I’ll use angle quotes «‥».

Note

On a US keyboard using Vim or Neovim, « is a digraph which can be entered via Control-k followed by «. Or if you’ve set up a Compose key, it’s Compose followed by « in any editor.

» is the same, but » instead.

Or you can use <<…>> in your code and ignore my recent obsession with fancy characters.

Yes, I know I could practically write it all with fancy characters in Raku. One step at a time.

Let’s go back to the Python code because it’s still so small.

Say I want to demonstrate the delightful Rich terminal library for Python.

Code sample
import-libraries
     from rich import print
 from rich.panel import Panel
 from rich.markdown import Markdown

But before I really use it in my code, I spend 1,500 words singing its praises.

It’s nice. I like it.

Okay, done singing. Time to write the rest of the program.

Code sample
rich-hello.py
    «import-libraries»

md = Markdown("**Hello**, *World*.")
print(Panel(md))

I identify the fragment with a name attribute:

Code sample
    {{< code name="import-libraries" lang="python" >}}
from rich import print
from rich.panel import Panel
from rich.markdown import Markdown
{{< /code >}}

My code block references the import-libraries fragment by name when I’m ready for it.

Code sample
    {{< code file="rich-hello.py" >}}
«import-libraries»

md = Markdown("**Hello**, *World*.")
print(Panel(md))
{{< /code >}}

Note

I might spend some time talking about the code shortcode in another post, but I dislike Go’s templating enough that this does not sound like fun.

Rounding up fragments to tangle

Recognizing an additional parameter doesn’t make my regular expression that much more complicated, but I can see things getting more complex. I could even find a better pattern later. Let’s give the params their own named regex for some encapsulation.

Code sample
shortcode-params-regex
    my regex params {
   'file="' $<filename> = .+? '"'
   ||
   'name="' $<fragment> = .+? '"'
}

That way I can drop it in shortcode to say “oh and look for params while you’re at it please.”

Code sample
nested-shortcode-regex
    «shortcode-params-regex»
my $opener = '{{< ';
my $closer = ' >}}';

my regex shortcode {
  $opener code \s <params> .*? $closer
  \n                # Ignore leading newline
  $<content> = .+?  # Remember everything else in the block
  \n                # Ignore trailing newline
  $opener '/code' $closer
}

Okay, we recognize file and name parameters. What do we do with them? We gather them!

Code sample
gather-fragments-and-files
    my %fragment-for;
my @filenames;
my $markdown = slurp $filename;

for $markdown.match(/<shortcode>/, :global) -> $block {
  my $tangle-content = $block<shortcode><content>;
  my $params = $block<shortcode><params>;
  my $fragment = $params<fragment> || $params<filename>;

  if $fragment {
    say "fragment: $fragment";
    %fragment-for{ $fragment.Str } = $tangle-content;
  }

  if my $filename = $params<filename> {
    @filenames.push($filename.Str);
  }
}

Tangling my fragments

Let’s see here. I know before I can write any files, I need to make sure everything’s tangled Trying to keep fragments easy to identify. They sit on a line by themselves, possibly with some leading whitespace.

Code sample
tangle-fragments
    my regex fragment { ^^ \h*? "«" $<name> = .+? "»" $$ }
my %tangle-for;

«tangle-function»

for %fragment-for.keys -> $name { tangle($name); }

Note

Raku functions are lexically scoped, which means it’s perfectly okay to declare a function inside another function. Though next time I revisit this, I may want to think about a class or something to hold the complexity.

But what does that function need to look like? I’m still not sure I got it quite right. I mean I know the basic shape of it.

Code sample
tangle-function
    sub tangle(Str $name) {
  «tangle-error-checking»

  «tangle-text»
}

It needs some error checking. I know that much. Oh, and if it’s already been tangled I should avoid going through it again.

Code sample
tangle-error-checking
       return "" unless $name;

   if %tangle-for{ $name } {
     return %tangle-for{ $name }.Str;
   }

   my $content = %fragment-for{ $name };
   unless $content {
     die "«$name» is not a valid fragment";
   }

The idea of the thing is clear enough. Find and recursively tangle each fragment found in this text, replacing the fragment references with their tangled text. Once that’s all done, cache and return the tangled text.

Code sample
tangle-text
       for $content.match(/ <fragment> /, :global) -> $match {
     my $fragment-ref = $match.Str;
     my $fragment-name = $match<fragment><name>.Str;
     say "$name ← «$fragment-name»";
     $content.subst-mutate(/$fragment-ref/, tangle( $fragment-name));
   }

   %tangle-for{ $name } = $content;

I flailed while tangling fragments. Lots of complaints from Raku about the difference between a Match and a String. There must be better ways. But the most important thing? I got it to work eventually.

Writing tangled files

After all that, writing the tangled files felt easy.

Code sample
write-tangled-fragments
       «define-commented-shortcodes»

   for @filenames -> $tangle-file {
     my $tangle-content = %tangle-for{ $tangle-file }
       .subst(:global, / $commented-opener /, $opener)
       .subst(:global, / $commented-closer /, $closer);
     spurt $tangle-file, $tangle-content;
     say "Tangled to $tangle-file";
   }

Then — theoretically — all these fragments I wrote will make a useful code tangler!

Might as well make it so this script can look at more than just the file I’m editing right now.

Code sample
tangle-fragments.raku
    sub MAIN(Str $filename) {
  «nested-shortcode-regex»

  «gather-fragments-and-files»

  «tangle-fragments»

  «write-tangled-files»
}

Easiest CLI I ever wrote, by the way. See?

Code sample
    $ raku tangle-fragments.raku
Usage:
  tangle-fragments.raku <filename>

Time for the real thing. I’m nervous. I shouldn’t be nervous. I know how this story ends. Then again I keep rewriting the middle.

Code sample
    $ raku tangle-fragments.raku index.md
fragment: hello.py
fragment: tangle.raku
fragment: define-commented-shortcodes
fragment: replace-commented-shortcodes
fragment: tangle-every-block
fragment: tangle-multi.raku
fragment: import-libraries
fragment: rich-hello.py
fragment: shortcode-params-regex
fragment: nested-shortcode-regex
fragment: gather-fragments-and-files
fragment: tangle-fragments
fragment: tangle-function
fragment: tangle-error-checking
fragment: tangle-text
fragment: write-tangled-files
fragment: tangle-fragments.raku
tangle-function <-- (tangle-error-checking)
tangle-function <-- (tangle-text)
nested-shortcode-regex <-- (shortcode-params-regex)
tangle-every-block <-- (replace-commented-shortcodes)
tangle-fragments <-- (tangle-function)
write-tangled-files <-- (define-commented-shortcodes)
tangle-fragments.raku <-- (nested-shortcode-regex)
tangle-fragments.raku <-- (gather-fragments-and-files)
tangle-fragments.raku <-- (tangle-fragments)
tangle-fragments.raku <-- (write-tangled-files)
rich-hello.py <-- (import-libraries)
tangle-multi.raku <-- (define-commented-shortcodes)
tangle-multi.raku <-- (tangle-every-block)
Tangled to hello.py
Tangled to tangle.raku
Tangled to tangle-multi.raku
Tangled to rich-hello.py
Tangled to tangle-fragments.raku

That overwrote my test version of tangle-fragments.raku. Scary. Ran the new version to keep myself honest. It produced the same output, and appears to have correctly tangled my fragments!

Code sample
Generated rich-hello.py
    from rich import print
from rich.panel import Panel
from rich.markdown import Markdown

md = Markdown("**Hello**, *World*.")
print(Panel(md))

Running rich-hello.py looks more interesting with a screenshot than a text block:

Formatted output using Rich
Formatted output using Rich

Okay. Now I’m done.

I could have done this in Python. There are decent parsing libraries out there. But Raku did this on its own, without pulling in any extra — without pulling in any libraries.

Done? You barely started!

My tangle script is no competition for Org mode’s Babel.

But it’ll do for now.
